DMG Series
Top-Entry Cartesian Robots
General Features
DMG Series Vertical-Entry Cartesian Robots
DMG Series
DMG 2
DMG 3
DMG 4
DMG 5
DMG 6
Key Advantages
Applications
The Dal Maschio DMG Series consists of high-performance Cartesian robots mounted on the fixed platen of injection-moulding machines and designed for vertical entry into and withdrawal from the mould area.
The robots move on three servo-controlled Cartesian axes: X, Y and Z. Depending on application requirements, they can also be equipped with one or more rotary heads driven by pneumatic or electric actuators.
DMG-series robots provide fast and versatile automation solutions adaptable to injection-moulding machines of different tonnages. Brushless electric motors and numerical control deliver precise, repeatable and controlled motion.
- Vertical-entry Cartesian robot design
- Servo-controlled motion on X, Y and Z axes
- Brushless electric motors
- Operation management via numerical control
- Programming of free or predefined motion sequences
- Integrated electrical cabinet
- Touchscreen operator interface
- Pneumatic or electric rotary-head options
- Compatibility with injection-moulding machines of different sizes and tonnages
- X Axis: 2000 - 2500 mm
- Z Axis: 800 mm
- Y Axis: 1200 - 1500 mm
- Maximum Payload: 18 kg
- Cycle Time: 7 seconds
- Press Capacity: up to 650 tonnes
- X Axis: 2500 mm
- Z Axis: 1100 mm
- Y Axis: 1700 mm
- Maximum Payload: 25 kg
- Cycle Time: 10 seconds
- Press Capacity: 500–800 tonnes
- X Axis: 3000 mm
- Z Axis: 1100 - 1500 mm
- Y Axis: 2000 - 2600 mm
- Maximum Payload: 45 kg
- Cycle Time: 13–15 seconds
- Press Capacity: 800–1,500 tonnes
- X Axis: 4000 mm
- Z Axis: 2000 mm
- Y Axis: 2500 mm
- Maximum Payload: 90 kg
- Cycle Time: 16 seconds
- Press Capacity: 1,000–2,500 tonnes
- X Axis: 5000 - 6000 mm
- Z Axis: 2500 - 3000 mm
- Y Axis: 3000 - 4200 mm
- Press Capacity: 2,000–8,000 tonnes
- Developed for large injection-moulding machines and extensive working areas
- Fast and precise part-removal operations
- High motion repeatability
- Wide model range adaptable to different machine tonnages
- Servo-controlled three-axis motion system
- Programmable motion sequences
- Architecture suitable for flexible automation applications
- Reduced operator intervention
- Optimised production cycles
- Touchscreen control interface for easy operation
- Part removal from injection-moulding machines
- Part handling and positioning
- Insert-placement applications
- Transfer of products to conveyor systems
- Pick & place applications
- End-of-line automation operations
- Medium- and high-tonnage injection-moulding machines
